Features
Servo motor driven
Can do stretch, compression, bending, shear test
Low noise, high efficiency
Can test metal, nonmetal, composite material
Automatic obtain of stretch strength, bending strength, yielding strength, elongation rate, elastic modulus, peel strength
Close-loop control, automatic data storage, test report generation
Can generate curves: stress-strain, loading-strain, loading-time, loading-displacement, displacement-time, deformation-time
Technical specifications
| Spec. | ETM-SH0.5 | ETM-SH1 | ETM-SH2 | ETM-SH5 |
| Max. Loading | 500N | 1kN | 2kN | 5kN |
| Test range | 2%—100%F.S | |||
| Loading relative accuracy | ±1%(±0.5%) | |||
| Displacement Measure resolution | 0.01mm | |||
| Deformation accuracy | ±1% | |||
| Speed regulation range | 1—500mm/min | |||
| Stretch effective space | 600mm or 1000mm | |||
| Frame type | Single beam or portal type | |||
| Main machine size | 600×400×1450mm or 1850mm | |||
| Weight | 180Kg | 200Kg | ||
