Описание
Standards: GB, ISO, ASTM, DIN
Features
Electric system: AC servo driver, AC servo motor, overcurrent, overvoltage, overspeed, overload protection device; speed ratio to 1:100000
Upper lower limit, emergency stop function available
Test modes available: constant speed loading, constant speed move, constant speed strain, constant speed loading cycle, constant speed deformation cycle, modes can be switched smoothly.
Electric control circuit features high interference ability, guarantee stable performance of controller
Internet interface equipped, easy for data transmission, storage, print, internet connection
Technical specifications
| Spec. | ETM-M |
| Comprehensive Test Precision | 1% |
| Loading | |
| Test range | 0-100kN, 2%-80%, 10/20/50/100kN Optional |
| Resolution | 1/200000 F.S |
| Load Relative Accuracy | ±1%(±0.5%) |
| Deformation index | |
| Max. value | 10mm |
| Measure range | 2%-100% |
| Relative Accuracy | ±1%(±0.5%) |
| Displacement | |
| Relative Accuracy | ±1%(±0.5%) |
| Resolution | 0.001mm |
| Speed | 0.005mm/min-500mm/min,stepless speed regulation |
| Relative accuracy | ±1%(±0.5%) |
| Stretch travel | 600mm |
| Compression travel | 600mm |
| Test width | 470mm |
| Working ambient | 10~35℃, 20%~80% RH |
