Standards: ASTM E18, ISO6508-2
Main Features
Optimization structure and appearance design
Automatic test process, avoid human operation error
Large LCD display
Test data direct print, RS232 port equipped
Oil buffer enable adjustable loading speed
Wide application and good adaptability
Test objects
Ferrous metal, non-ferrous metal, non-metal material
Heat treatment material
Specially suitable for parallel surface precision measure, stable and reliable test for curved surface
Technical Specifications
Test range: 20-88HRA, 20-100HRB, 20-70HRC
Test power: 588.4,980.7, 14 71N(600/100/150Kgf)
Allowed specimen Max height: 210mm
Pressure head to wall distance: 165mm
Hardness resolution: 0.1HR
Overall size: 522 x 220 x 729mm
Weight: approx 98kg
Main accessories
Large platform: 1pc
Diamond cone pressure head: 1pc
Small test platform: 1/16”1pc
Steel ball pressure head: 1pc
V type test platform: 1pc
Standard Rockwell hardness block: 5pcs
Printer: 1set
