Features
◆ The oven inside is made of stainless steel, the cover is made of high quality steel plate, it has nice appearance and rational structure.
◆ The micro-computer temperature controller has temperature control protection, digital display, it also has timing function.
◆ The hot air circulating system is comprised of fan and channel, with uniform temperature inside.
Technical Specification
| Model | 9030A 9030 (101-0) | 9070A 9070 (101-1) | 9140A 9014 (101-2) | 9240A9240(101-3) | 9420A(101-4) | 9620A |
| Power supply | 220V 50HZ | 380V 50HZ | ||||
| Temperature Control Range | RT+10-300℃ | |||||
| Temperature Fluctuation | ±1℃ | |||||
| Temperature control accuracy | 1% | |||||
| Input Power | 800W | 1200W | 1600W | 2100W | 2500W | 3100W |
| Cubage | 30L | 80L | 136L | 220L | 420L | 620L |
| Oven Size(mm) | 300*300*350 | 450*400*450 | 5500*450*550 | 600*500*750 | 600*550*1300 | 800*600*1300 |
| Overall size(mm) | 620*490*490 | 740*580*630 | 840*670*730 | 880*720*930 | 780*750*1880 | 980*800*1880 |
| Timing Range | 1-9999min | |||||
| Model | 9035A | 9055A | 9075A | 9145A | 9245A | 9425A | 9625A |
| Power supply | 220V 50HZ | ||||||
| Temperature Control Range | RT+10-300℃ | ||||||
| Temperature Fluctuation | ±1℃ | ||||||
| Temperature control accuracy | ±1% | ||||||
| Input Power | 1000W | 1200W | 1600W | 2100W | 2500W | 3100W | 4000W |
| Cubage | 30L | 50L | 80L | 136L | 220L | 420L | 620L |
| Oven Size(mm) | 300*300*350 | 415*370*345 | 450*400*450 | 550*450*550 | 600*500*750 | 600*550*1300 | 800*600*1300 |
| Overall size (mm) | 620*490*490 | 720*610*520 | 740*580*630 | 840*670*730 | 800*720*930 | 780*750*1880 | 980*800*1880 |
| Timing range | 1-9999min | ||||||
Noted terms:
1． Make sure the cover should be earthed well.
2． The equipment should be located in good ventilation place, make sure there is no flammable and combustible around the equipment.
3． It’s strictly prohibited to dry any flammable and combus
4． The oven inside can’t be too crowded, left some space for air circulation.
5． Keep the oven clean, keep it in drying room with dust-proof shield on cover if it will stop work for long time.
