Features
Direct measurement
Light in weight, easy structure, easy operation, wide applications
Stable performance, high measuring accuracy, system automatic compensation
15 different kinds of wire diameter measuring function, wider measurement range
Suitable for flexible rope, such as steel wire ropes
Technical specifications
| Model | RTM-2T | RTM-5T | RTM-10T | RTM-20T |
| Max loading | 20 | 50 | 100 | 200 |
| Loading resolution | 0.01 | 0.01 | 0.01 | 0.01 |
| Measuring range of rope diameter | 6-40mm | |||
| Measuring accuracy | 2%-6%, decided by rope type | |||
| Output interface | RS232 9 hole plug | |||
| Power supply | Rechargeable battery, | |||
| Working temperature | 5-35 degree C | |||
| Transportation temperature | -10-60 degree C | |||
| Relative humidity | 15%-80%RH | |||
| Working environment | No vibration source, no corrosive medium | |||
| Net weight | 5kg | |||
| Overall dimension | 650*375*100mm | |||
