Описание
The axial extensometer is specially used for axial deflection testing, it can test parameters such as elastic modules E, specified non-proportional extention lengthRpxx, total extention lengthRtxx, specific elongation, strain hardening exponent n and so on.
Specifications
| Model | YZ5/2.5(N) |
| Scale distance | 5mm |
| Maximum deflection | 2.5mm |
| Strain gage resistance | 350Ω |
| Bridge voltage | ≤5V (direct current or alternating current) |
| Output sensitivity | About 2.3mv/V |
| Output interface | USB(select by request) |
| Clamping method | Elastic band or torsion spring(N model) |
| Photo |
| Model | YZ10/3 |
| Scale distance | 10mm |
| Maximum deflection | 3mm |
| Strain gage resistance | 350Ω |
| Bridge voltage | ≤5V (direct current or alternating current) |
| Output sensitivity | About 1.5mv/V |
| Output interface | USB(select by request) |
| Clamping method | Elastic band |
| Model | YZ25/5(N) |
| Scale distance | 25mm |
| Maximum deflection | 5mm |
| Strain gage resistance | 350Ω |
| Bridge voltage | ≤5V (direct current or alternating current) |
| Output sensitivity | About 2mv/V |
| Output interface | USB(select by request) |
| Clamping method | Elastic or torsion spring clamping(N model) |
| Model | YZ25/10(N) |
| Scale distance | 25mm |
| Maximum deflection | 10mm |
| Strain gage resistance | 350Ω |
| Bridge voltage | ≤5V (direct current or alternating current) |
| Output sensitivity | About 2mv/V |
| Output interface | USB(select by request) |
| Clamping method | Elastic band or spring clamping(N model) |
| Model | YZ50/5 (N) |
| Scale distance | 50mm |
| Maximum deflection | 5mm |
| Strain gage resistance | 350Ω |
| Bridge voltage | ≤5V (direct current or alternating current) |
| Output sensitivity | About 2mv/V |
| Output interface | USB(select by request) |
| Clamping method | Elastic band or spring clamping(N model) |
| Model | YZ50/10(N) |
| Scale distance | 50mm |
| Maximum deflection | 10mm |
| Strain gage resistance | 350Ω |
| Bridge voltage | ≤5V (direct current or alternating current) |
| Output sensitivity | About 2.3mv/V |
| Output interface | USB(select by request) |
| Clamping method | Elastic band or spring clamping(N model) |
| Model | YZ50/25(N) |
| Scale distance | 50mm |
| Maximum deflection | 25mm |
| Strain gage resistance | 350Ω |
| Bridge voltage | ≤5V (direct current or alternating current) |
| Output sensitivity | About 2.3mv/V |
| Output interface | USB(select by request) |
| Clamping method | Elastic band or spring clamping(N model) |
| Model | YZ75/25(N) |
| Scale distance | 75mm |
| Maximum deflection | 25mm |
| Strain gage resistance | 350Ω |
| Bridge voltage | ≤5V (direct current or alternating current) |
| Output sensitivity | About 2.3mv/V |
| Output interface | USB(select by request) |
| Clamping method | Elastic band or spring clamping(N model) |
| Model | YZ100/5(N) |
| Scale distance | 100mm |
| Maximum deflection | 5mm |
| Strain gage resistance | 350Ω |
| Bridge voltage | ≤5V (direct current or alternating current) |
| Output sensitivity | About 2 mv/V |
| Output interface | USB(select by request) |
| Clamping method | Elastic band or spring clamping(N model) |
| Model | YZ100/10(N) |
| Scale distance | 100mm |
| Maximum deflection | 10mm |
| Strain gage resistance | 350Ω |
| Bridge voltage | ≤5V (direct current or alternating current) |
| Output sensitivity | About 2.3 mv/V |
| Output interface | USB(select by request) |
| Clamping method | Elastic band or spring clamping(N model) |
| Model | YZ200/20 |
| Scale distance | 200mm |
| Maximum deflection | 20mm |
| Strain gage resistance | 350Ω |
| Bridge voltage | ≤5V (direct current or alternating current) |
| Output sensitivity | About 1.8 mv/V |
| Output interface | USB、D9(select by request) |
| Clamping method | Elastic band |
| Model | YZ25/5M |
| Scale distance | 25mm |
| Maximum deflection | 5mm |
| Testing accuracy | 0.5 grade |
| Strain gage resistance | 350Ω |
| Bridge voltage | ≤5V (direct current or alternating current) |
| Output sensitivity | About 2.0 mv/V |
| Output interface | USB(select by request) |
| Clamping method | Spring clamping |
| Model | YZ25/5M |
| Scale distance | 50mm |
| Maximum deflection | 10mm |
| Strain gage resistance | 350Ω |
| Bridge voltage | ≤5V (direct current or alternating current) |
| Output sensitivity | About 2.3 mv/V |
| Output interface | USB(select by request) |
| Clamping method | Spring clamping |
