Technical Specifications
| Working Condition | |
| Temperature range | 10℃~35 |
| Relative humidity | 80% |
| Ambient environment | No vibration, no corrosion, no magnetic interference |
| Power supply | 220V,50Hz, fluctuation ±10% |
| Testing condition(besides the above conditions) | |
| Temperature | 18℃~28℃, temperature fluctuation ±2 |
| Relative humidity | 75% |
| Ambient environment | No obvious air flow |
| Technical Specifications | |
| Scale length | 10 mm |
| Max deformation | 4 mm |
| Measuring accuracy | ±1% |
| Strain gage resistance value | 350Ω |
| Bridge power | ≤5V(AC, DC) |
| Output sensitivity | Approx 2 mv/V |
| Output end terminal | USB( others on request) |
| Clamping way
| Integrate edge and sample |
| Use screw to fix the edge on the sample, install the extensometer between the blades | |
