Описание
Standards
ASTM D4595, BS EN ISO 10319, EN ISO 12236(GB/T14800), ASTM D4833, ASTM D5034, ASTM D5035, ASTM D-4533, BS6906.1,GB/T16989
Features
- Smart touch interface, 5.7-inch super large screen, click at will.
- The load cell adopts a 0.5-level high-precision load cell.
- Adopt the international high-end all-aluminum alloy shape design, and the surface is treated with sandblasting and anodizing process.
- The Chinese and English dual interface can be switched arbitrarily, and the test curve, graph, and data can be displayed dynamically.
- Adopt advanced digital signal processing (DSP) technology, Philips 32-bit full digital control and 2500 f/s high-speed data acquisition.
- Taiwan precision pre-loaded ball screw, no backlash, high positioning accuracy.
- Non-clutch drive device, capable of running at full speed under maximum force.
- Fully comply with “Mechanical Equipment 2006/42/EC”, “Low Voltage 2006/95/EC”, “EMC Directive 20044/108/EC” and GOST-R;
Technical specifications
| Model | GT-010 | GT010D |
| Test method & Control | CRE principle, microcomputer control, LCD display, support for online | CRE principle, microcomputer & computer dual control, dual-screen display |
| Test load | 5KN;10KN; 30KN; 50KN | |
| Sampling frequency | 2500hz | 2500hz |
| Measuring force range | 1%~100% of full scale | 1%~100% of full scale |
| Force measurement accuracy | ≤±0.02%F.S | ≤±0.02%F.S |
| Stretching speed | 0.05-500mm/min | 0.05-500mm/min |
| Effective stroke of beam | 800mm Resolution: 0.01mm | 800mm Resolution: 0.01mm |
| Holder: wide strip tensile test | width 200mm; tear test: width 100mm | width 200mm; tear test: width 100mm |
| CBR burst test | φ50×100mm | φ50×100mm |
| Power supply: | AC220V±10% 50Hz 1.5KW | AC220V±10% 50Hz 1.5KW |
| Dimensions | 860×600×1800mm | 860×600×1800mm |
| Weight | 300kg | 320kg |
Applicable tests
| Tests type | Suggested load | Test parameters | Standards |
| 1.Wide-width tensile & elongation | 10000N 50000N
| 1. Clamper width: 220mm Sample width: 200mm 2. Clamp distance: 100mm | BS EN ISO 10319 |
| 2.Trapezoidal Tear test | ASTM D-4533 | ||
| 3.CBR puncture test | 50000N | 1. Mandrel Dia.: 50mm Circular clamper inner dia.: 150mm sample dia.:230mm 2. Press rate: 60mm/min | EN ISO 12236(GB/T14800) |
| 4.Puncturing test | 10000N | 1. Mandrel diameter: 8mm Inner diameter of ring fixture: 44.5mm Sample diameter: 120mm 2. Pressing speed: 30mm/min | GB/T17643, ASTM D4833 |
| 5. Breaking force and elongation strength test | 10000N 50000N | 1. Width of holder: 25mm Sample width: 100mm 2. Stretching speed: 100mm/min 3. Clamping distance: 75mm | ASTM D5034, D5035 |
