Описание
Standards: GB/T9370-1999 ,JJG269-2006, ISO,JIS,ASTM,JIN
Features
1. Full automatic test
2. Horizontal spring clamping
3. High accuracy, faster test speed.
Functions
Preset test parameters, can indicate test results with only one press
Mainly test the spring torsion, torque, torsion angle, stiffness, if equipped with fixtures can test other parts;
LCD display, easy operation
Peak value maintain, stiffness calculation, overload automatic stop, data query and print
Multifunctional, higher resolution display
Rotate left or right freely, reset torsion and torsion angle at any point freely.
Technical specifications
| Model | TNZ-1000H | TNZ-2000H | TNZ-5000H | TNZ-10000H | TNZ-50000H | TNZ-100000H |
| Load range | 0-1000N.mm | 0-2000N.mm | 0-5000N.mm | 0-10000N.mm | 0-50000N.mm | 0-100000N.mm |
| Load resolution | 0.01N.mm | 0.1N.mm | 1N.mm | |||
| Angle min value | 0.1°/0.01° | |||||
| Max angle | 0±9999.9° | |||||
| Torsion platen axial distance | 75mm | 210mm | 660mm | |||
| Test accuracy | ±1%, ±0.5% | |||||
| Control mode | Touch screen parameters setup, test results automatic print | |||||
| Overload protection | alarm automatic stop | |||||
| Net weight | 50kg | 85kg | 175kg | |||
| Power supply | AC 220V±10% / 50Hz | |||||
| Overall size | 660×500×410 (mm) | 860×500×410(mm) | 1560×550×1110(mm) | |||
