Standards: GB/T4340.2, ISO6507-2, ASTM E92
Features
Friction free main shaft structure, high test accuracy
Automatic test, easy operation, no human error
Data automatic input, automatic lcd display, printer print test result
Lcd display, menu operation
Ccd imaging system optional
Applications
Carburized layer, ceramic, steel, non-ferrous metal
Thin sheet, metal sheet, galvanized coating
Nitration case, carburized layer, quench hardening layer gradient measurement
Suitable for parallel plane and micro parts & ultrathin parts precision vickers hardness measurement.
Technical specifications
Measuring range: 5-2900HV
Test load: 9.807,49.03,98.07,196.1,294.2,490.3N（1,5,10,,20,30,50gf)
Sample max allowed height: 180mm
Indenter center to machine all distance: 125mm
Measuring system amplification rate: 125X,250X
Min measuring unit: 0.06μm
Overall size: 580*260*730mm
Power supply: AC220V,50/60Hz
Net weight: 90kg
Standard Configuration
Coordinate test bench: 1pc, quill shaft test bench: 1pc, thin sheet test bench: 1pc
Large v shape block: 1pc, small v shape block: 1pc
Diamond pyramid indenter: 1pc
Standard Vickers hardness block: 2pc, standard microscope hardness block: 1pc
Micro Printer: 1pc
