Model: TGJ-1
Description
The K0 consolidation apparatus is used to test the static lateral pressure coefficient of Ø61.8mm soil specimen.
Technical specifications
1. Specimen size: Ø61.8 x 40mm
2. Axial loading: 6KN
3. Pore pressure: 0-1000KPa
4. Axial displacement: 0–10mm
5. Ambient temperature: 20±5℃, RH<85%
6. Proving ring relative error: <±1‰, Height relative error: ±2‰
7. Axial relative displacement error: 0.03mm, minimum resolution: 0.01mm
9. Volume change< 0.2ml
