Model: ZNJ-6
Application
Bonding strength test of Tapestry brick, mosaic, board, paint, coating, outer wall building materials.
Standards
JGJ/110-2008
Features
1. No oil cylinder design, concise structure, easy maintenance, high production efficiency.
2. Integration design of display and main machine, portable and stable;
3. S type low alloy steel sensor, no machine abrasion, no need for linearity offset, stable & reliable data acquisition
4. Outer connect Portable printer, easy data management;
5. USB upper computer communication, upper computer process data, output other format files;
6. Lithium battery enable longer working hour.
7. Automatic results calculation, timely data output.
8. Pull sensor direct measure guarantee longer tooling life, higher measure accuracy.
Technical specifcations
| No. | Term | Spec. |
| 1 | Main structure | Oil-free design |
| 2 | Standard brick size | 95mm×45mm, 40mm×40mm |
| 3 | Maximum pull force | 6KN |
| 4 | Main machine material | High quality alloy aluminum |
| 5 | Main machine weight | 2.5 kg |
| 6 | Automatic shut-off time(min) | 5 |
| 7 | Menu language | English |
| 8 | Indication resolution(KN) | 0.001 |
| 9 | Testing range(KN) | 0-6 |
| 10 | Overload indication(KN) | 6.2 |
| 9 | Peak lockout function | √ |
| 10 | Data storage capacity | 100 |
| 11 | Data Query and delete | √ |
| 12 | Sensor | S type low alloy steel sensor |
| 13 | Accuracy | ≤±1.0% |
| 14 | Repeatability | ≤1.0% |
| 15 | Gamut line correction | No need for correction |
| 16 | OLED display | 1.5 |
| 17 | 1200mAH High capacity lithium battery | ●√ |
| 18 | Charging process prompt function | ●√ |
| 19 | Low electric quantity prompt function | ●√ |
| 20 | Status indication function | ●√ |
| 21 | Time setting function | ●√ |
| 22 | KN/Mpa Unit switch function | ●√ |
| 23 | USB data transmission | ●√ |
| 24 | USB interface charging function | ●√ |
| 25 | Infrared data transmission function | ●√ |
| 26 | Portable printer | Optional |
| 27 | Test report automatic generation function | ●√ |
| 28 | Upper computer data edit function | ●√ |
