Features
Nice appearance, robust mainframe
English operation menu, friendly hmi for foreign users, easy in operation
Servo controlled, automatic operation, higher efficiency
Suitable for both metal and non-metal materials
Higher accuracy
Technical specifications
| Spec. | YTM-1000H | YTM-600H | |||
| Accuracy degree | 0.5% | 0.5% | |||
| Max. Test power | 1000kN | 600kN | |||
| Test power range | 10~1000 kN | 6~600 kN | |||
| Indication value accuracy | ±0.5% Indication value | ±0.5% Indication value | |||
| Displacement resolution | 0.005mm | 0.005mm | |||
| Displacement test accuracy | ±0.5% Indication value | ±0.5% Indication value | |||
| Deformation test resolution | 0.001mm | 0.001mm | |||
| Piston Max. Stroke | 680mm | 680mm | |||
| Stretch jaw Max. Space( including piston stroke) | 700mm | 700mm | |||
| Deformation test accuracy | ±0.5%Indication value | ±0.5%Indication value | |||
| Overload protection | 5% F.S | 5% F.S | |||
| Clamping way | Hydraulic wedge shape clamp | Hydraulic wedge shape clamp | |||
| Round sample clamping range | Φ14~φ60(mm) | Φ14~φ60(mm) | |||
| Flat sample clamping range | 0~60(mm) | 0~60(mm) | |||
| Column number | 4 | 4 | |||
| Mainframe overall size | 1000×750×3160 (mm) | 1000×750×3160(mm) | |||
| Total power | 7.5 kw | 7.5 kw | |||
| Mainframe weight | Approx 5000kg | Approx 4500kg | |||
