Standards: GB/T11832-2002, GB/T11831-2002
Features
Double direction tipping board improved the measuring accuracy;
Stable water storage, good repeatability
Tipping board has shock absorption function, less rebound, better performance
Stainless steel rain tube edge, stainless steel filter
Full stainless steel made: tipping bucket, receiving funnel, drainage funnel, support, base.
Technical specifications
| Model | YLJD-02 | YLJD-05 |
| Resolution | 0.2mm | 0.5mm |
| Tipping bucket angle | 20°-25° | 20°-25° |
| Receiving tube diameter | 200mm | 200mm |
| Edge angle | 40-45° | 40-45° |
| Rainfall range | 0.01mm/min-4mm/min, Max allowed rainfall: 8mm/min | |
| Accuracy degree | ±3%, ±2% | ±2%, ±1% |
| Measuring range | ≤±4%(unidirectional tipping board)≤±3%(biodirectional tipping board) | ≤±3%(unidirectional tipping board)≤±2%(biodirectional tipping board) |
| Output signal | two-way reed switch switching value signal | |
