Features
Digital vacuum gauge automatic control vacuum degree, provide accurate and effective vacuum control, panel operation control, the vacuum degree can be controlled within 1.0×10 to 1.0×105（Pa）-1, resistance silicon tube pressure transducer guarantee stable pressure value
Microcomputer temperature control
Heating parts installed on the plates, reduced the heating time compared to traditional cabinets
Large LCD display, easy operation and reading
Aluminum material made for shelf, oxidation resistant under high temperature, fast heat induction, reduced the heat loss
Cuboid working chamber makes maximum working space
Tempered shot-proof Double layer glass door for easy observation, can fill with noble gas inside
Free adjustment of the door tightness, whole shaping silicon rubber doorseal guarantee high vacuum degree of cabinet
Liner made of stainless steel, enclosure made of high quality cold rolling steel sheet with static plastic sprayed
No oxygen or filled with noble gas for storage, heating, test, drying, won’t result oxidation
Technical Specifications
| Term | DZF-6020L | DZF-6050L | DZF-6090L | DZF-6210L | DZF-6500L |
| Power Supply | AC220V 50HZ | AC380V 50HZ | |||
| Temperature Range | RT+10~250 | ||||
| Temperature Fluctuation | ±1 | ||||
| Temperature Resolution | 0.1 | ||||
| Vacuum Degree | 1000kPa—2kPa | ||||
| Input Power | 450W | 1200W | 1400W | 2200W | 3500W |
| Working Chamber SizeW×D×H(Mm) | 300300275 | 415370345 | 450450450 | 560600640 | 630810845 |
| Overall SizeW×D×H(Mm) | 5904701370 | 7105101430 | 6156601440 | 7208051680 | 79010301855 |
| Capacity | 20L | 50L | 90L | 210L | 500L |
| Support Tray | 1pcs | 2pcs | 3pcs | 4pcs | |
| Liner Material | Stainless steel | ||||
| Timing Range | 1~9999min | ||||
| Equipped with vacuum pump and drying chamber | |||||
Optional Parts
Intelligent controller
Noble gas inlet valve
Air liquids separator
Vacuum drying chamber
Cabinet （6020/6030/6050）
2XZ-2 model Vacuum pump
2XZ-4 Vacuum pump
