Model: JC-MC01
Standards
GB/T 7106-2019 Test Method for Air Tightness, Water Tightness and Wind Pressure Resistance of Building External Windows and Doors
EN 1026 air tightness for windows and doors
EN 1027 Water tightness for windows and doors
EN 12211 Wind load test for windows and doors
En 14351 part 1 performance characteristics for Windows and external pedestrian door sets
Specifications
| Working power supply | 380VAC, 15KW |
| Wind pressure measure range | -600Pa~600Pa -5000Pa~5000Pa |
| Air flow measure range | 0-500m3/h |
| Spray measure range | 100-1000L/h; 100-2000L/h, accuracy ±2.5% |
| Displacement measure range | 0-50mm |
| Pressure transmitter accuracy | ±0.25% |
| Air flow meter accuracy | ±3% |
| Displacement measure accuracy | 0.25% |
| Control cabinet dimensions | L950*W600*H870mm |
| Static pressure chamber dimensions | 2500*1750*2800mm |
| Max test window size | 2.4m*2.4m, other dimensions custom made |
| System max power | 13KW |
| Installation space dimensions | 5000*5500*4000mm |
